WEC-SBTR

This product belongs to the "Sprite" series core board of Hangzhou Yanzhi Technology Co., Ltd. It has extremely strong compatibility and is compatible with other core boards of the Sprite series.

Equipped with the Intel Celeron J1900 processor, with a clock speed of up to 2.4 GHz, it can support up to 8GB of memory. It supports 2 Gigabit network interfaces, with 10/100/1000Mbps auto-adaptation; 1 USB 3.0, 4 USB 2.0. Supports 6 COM ports and 2 CAN ports; integrates an FPGA chip, which can provide 33 high-speed I/O; 16 GPIO ports and 4 PCIe 3.0 ×1.

▇   Key features of the Spirit series core board products:

◐  Cross-platform compatibility: The Sprite series core boards are compatible with multiple processor platforms such as x86 and ARM architectures

◐  Interface compatibility: The Sprite series core boards all adopt the MXM interface

◐  Signal compatibility: The Sprite series core boards define the pin signals according to unified rules

◐  Provide high-speed IO: The Sprite series core boards integrate FPGA chips and can provide over 30 high-speed IO channels

The same Base-board can be compatible with all the core boards of the Sprite series

Click or scan the QR code

to download the product specification
