WEB-C111X

◐ It has strong compatibility, and can be compatible with all core boards of WEC-CTGL and WEC-CEHL
◐ Support SATA, mPCIe, M.2 interface SSD hard disk
◐ 2 × HDMI 2.0 display
◐ 3 × Gigabit Ethernet

◐ Support 4G/5G wireless network
◐ 2 × RS232/RS422/RS485, 4 × RS232，DB9
◐ 4 × USB 3.0, built-in 4 × USB 2.0
◐ Support 9-28 V wide voltage input

Order

IntroduceModelSizeTechnical

This product belongs to the matching base-board of the WEC-Cxxxx series core-board of Hangzhou Yanzhi Technology Co., Ltd., which has super compatibility and can be compatible with all core boards of WEC-CTGL and WEC-CEHL series.

Abundant external peripheral interfaces, support SATA, mPCIe, M.2 interface SSD hard disk. support 2 HDMI 2.0 display, 3 Gigabit Ethernet, 4G/5G wireless network; 6 serial ports (DB9), including 2 RS232/RS422/RS485 and 4 RS232; 4 USB 3.0, built-in 4 USB 2.0. Support 9-28V wide voltage input.

▇ Compatible performance features:
◐ Cross-platform compatibility: Compatible with Intel's 11th Gen Core Tiger Lake series and 12th Gen Celeron Elkhart Lake series processor core boards (WEC-CTGL and WEC-CEHL)
◐ Interface compatibility: MXM physical interface is used

◐ Signal compatibility: Pin signals are defined according to uniform rules

The same base-board can be adapted to WEC-CTGL and WEC-CEHL series core boards.

Product Model	WEB-C111X
Memory	SATA	1 × SATA 2.0，upright A-type socket, support SATA hard drives
	SSD	1 × mini PCIe，support mSATA SSD
	SSD	1 × M.2 M-key PCIe 3.0，support 2242/2280 NVMe SSD
Display	HDMI	2 × HDMI 2.0 Type-A
	eDP	1 × single-channel 4-wire eDP
	LVDS	2 × 4-channel 24-bit LVDS
	MIPI-DSI	Single-channel output and multiplexed with LVDS plugins
Net	Ethernet	3，10/100/1000Mbps，RJ45
	4G/5G	1 × mPCIe for 4G module，1 × M.2 B-key for 5G module；1 × Micro SIM card slot
	WIFI	WIFI 2.4G
	Bluetooth	Bluetooth 4.2
IO Interface	USB	4 × USB 3.0，Type A；built-in 4 × USB 2.0
	COM	2 × RS232/422/485（isolated），4 × RS232（isolated），DB9
	CAN	2，provided when WEC-CTGL core board is adopted
	GPIO	8
	RTC	Support
	Audio	1 × L&R Line-Out，1 × MIC In， 2 in1 3.5mm Jack
Power Supply	Type	DC
Power Supply	Input Voltage	9~28 V
Environment	Operating Temp.	-10 ~ 60 °C
	Storage Temp.	-40 ~ 85 °C
	Operating Humidity	10-95% @40℃，non-condensing
	Storage Humidity	0-95% @60℃，non-condensing
Dimension	Outside Dimension	147.3mm×189.4mm
